HLP Led Modular Spotlight 2
|
Category: |
Industry, Outdoor, Spotlight |
|
Power Consumption: |
300W, 450W, 600W |
|
Input Voltage: |
AC 240V |
|
Color: |
3000K, 4000K, 6500K |
|
Power Factor: |
>0.95 |
|
Ingress Protection: |
IP65 |
|
Warranty: |
3 Years Warranty |
|
{{variant.name}}:
|
{{opt.name}}
{{opt.name}}
|
Description
| Performance | |||
|---|---|---|---|
| Model |
HLP-AML4-XXD300-PZ-V |
HLP-AML6-XXD450-PZ-V |
HLP-AML8-XXD600-PZ-V |
| Input Voltage | AC110-260V | ||
| Input Current | 1.32A | 1.98A | 2.63A |
| Power Consumption | 300 Watts | 450 Watts | 600 Watts |
| Power Factor | >0.95 | ||
| Power Efficiency | 90% | ||
| Frequency | 50Hz | ||
| Beam Angle | 25°/40°/60°/90° | ||
| Typical Luminous Flux (LM) | 36550 | 54830 | 73100 |
| Luminous Efficiency (LM/W) | 121.83 | 121.84 | 121.83 |
| Color Rendering Index (CRI) | 70 | ||
| Color Temperature (CCT) | 3000K, 4000K, 6500K | ||
| Color | Warm White(WW), Natural White(NW), White(W) | ||
| Dimensions | |||
| Product Length (mm) | 565 | 565 | 565 |
| Product Width (mm) | 210 | 310 | 415 |
| Product Height (mm) | 125 | 125 | 125 |
| Gross Weight (Kg) | 0 | 0 | 0 |
| Material | |||
| Housing | Aluminum | ||
| Lens | Polycarbonate | ||
| Body Color | Silver | ||
| Led Chip | LED Lumileds 3030 | ||
| Led Driver | MOSO | ||
| Ingress Protection | IP65 | ||
| Longevity | |||
| Lifetime (Hours) | 30000 | ||
| Warranty (Years) | 3 | ||
| Application Area | |||
| Out door car park, Sports Stadium, Tennis court | |||
